Nolathane 47015 Rear Axle Leaf Spring - Rear Eye and Shackle Bushing Kit
Nolathane
Vehicle Search
Vehicle
Search
OR
Nolathane
47015
Rear Axle Leaf Spring - Rear Eye and Shackle Bushing Kit
*** CONTACT NOLATHANE ***
47015
Rear Axle Leaf Spring - Rear Eye and Shackle Bushing Kit
*** CONTACT NOLATHANE ***
click to enlarge
click to enlarge click to enlarge click to enlarge click to enlarge click to enlarge click to enlarge
Vehicle Kit Contains:
Improves steering, corner precision, and driving experience; the best, replacement upgrade. Includes:

A critical service item for any leaf sprung vehicle. High kilometres and heavy load carrying causes excessive wear on rubber bushings. Nolathane's signature red bushings are made tough and offer outstanding abrasion resistance, high load bearing capability (4WD's, utes and towing), flexibility, increased tensile strength and chemical resistance to oil, grease, ozone and weathering.
Kits Required: 1
Warranty: lifetime warranty
Kit Contents: 8 Bushings
Important Notes
US $ NAN
shipping
Calculate shipping?
Click here for rates & other info
Contents
Kit Contains;

Improves steering, corner precision, and driving experience; the best, replacement upgrade. Includes:

Contents
Kit Contains;

Improves steering, corner precision, and driving experience; the best, replacement upgrade. Includes:
Features
✓
The latest in material formulation technology boasts resistance to oil, grease, ozone and weathering.
✓
Supplied with extreme pressure molybdenum disulphide (LM) based grease for extended life.
✓
Internal grease reservoirs provide continual self-lubrication for optimum friction management.
✓
Designed with the installer in mind by reducing the need of specialised skills, tools and equipment.
✓
This kit is covered by a limited lifetime warranty including parts and labour.

Features
✓
The latest in material formulation technology boasts resistance to oil, grease, ozone and weathering.
✓
Supplied with extreme pressure molybdenum disulphide (LM) based grease for extended life.
✓
Internal grease reservoirs provide continual self-lubrication for optimum friction management.
✓
Designed with the installer in mind by reducing the need of specialised skills, tools and equipment.
✓
This kit is covered by a limited lifetime warranty including parts and labour.
Kit Specifications
Bush
Type		 Bush
Qty		 OD
(A)		 ID
(B)		 L
(C)		 FL
(D)		 FLOD
(E)		 C/Tube
QTY		 C/Tube
Size		 Similar
Bushing Size
1 8 35.3 mm 14.2 mm 38.5 mm 9.5 mm 49.2 mm click here
Looking for that hard-to-find part? Start your search here Nolathane Bushing Type & Size Register
Kit Specifications
Bush Type 1
Bush Qty 8
OD (A) 35.3 mm
ID (B) 14.2 mm
L (C) 38.5 mm
FL (D) 9.5 mm
FLOD (E) 49.2 mm
C/Tube QTY
C/Tube Size
Similar Bushing Size click here

Looking for that hard-to-find part? Start your search here Nolathane Bushing Type & Size Register

Installation
Install
Guide		 Fitment
Time		 Degree of
Difficulty		 Recommend
Wheel Alignment
2 hrs DIY - Do it yourself
Press Sleeve #
(IN)		 Press Plate #
(IN)		 Press Sleeve #
(OUT)		 Press Plate #
(OUT)		 Support
Sleeve #		 Press
Plate #		 Threaded
Rod #		 Press In/Out
Kit
Not Applicable Not Applicable 02 Even A 05 Odd A M14 NTK001

Use the above press Sleeves, Plates and Rods from the Nolathane Press In/Out kit NTK001 to aid in the ease of removing old worn and broken suspension bushings and installing New Nolathane bushings.

Installation
Install
Guide		 Fitment
Time		 Degree of
Difficulty		 Recommend
Wheel Alignment
2 hrs DIY - Do it yourself
Press Sleeve # (IN) Not Applicable
Press Plate # (IN) Not Applicable
Press Sleeve # (OUT) 02
Press Plate # (OUT) Even A
Support Sleeve # 05
Press Plate # Odd A
Threaded Rod # M14
Press In/Out Kit NTK001

Use the above press Sleeves, Plates and Rods from the Nolathane Press In/Out kit NTK001 to aid in the ease of removing old worn and broken suspension bushings and installing New Nolathane bushings.

Videos

How Hard Is Nolathane?

Larko Talks Bushing Lubrication
Videos

How Hard Is Nolathane?

Larko Talks Bushing Lubrication
47015
Vehicle Applications
47015 is suitable for the following vehicles. Select a vehicle for specific fitment details:
FORD FAIRLANE 1967-1969 - FAIRLANE ZA, ZB
FORD FAIRLANE 1969-1972 - FAIRLANE ZC, ZD
FORD FAIRLANE 1972-1976 - FAIRLANE ZF, ZG
FORD FAIRLANE 1976-1979 - FAIRLANE ZH
FORD FAIRLANE 1979-1982 - FAIRLANE ZJ
FORD FAIRMONT 1967-1969 - FAIRMONT XR, XT WAGON
FORD FAIRMONT 1967-1969 - FAIRMONT XR, XT SEDAN
FORD FAIRMONT 1969-1972 - FAIRMONT XW, XY SEDAN
FORD FAIRMONT 1969-1972 - FAIRMONT XW, XY WAGON
FORD FAIRMONT 1972-1976 - FAIRMONT XA, XB WAGON
FORD FAIRMONT 1972-1976 - FAIRMONT XA, XB SEDAN AND COUPE
FORD FAIRMONT 1976-1979 - FAIRMONT XC SEDAN AND COUPE
FORD FAIRMONT 1976-1979 - FAIRMONT XC WAGON
FORD FAIRMONT 1979-1982 - FAIRMONT XD WAGON
FORD FAIRMONT 1979-1982 - FAIRMONT XD SEDAN
FORD FAIRMONT 1982-1993 - FAIRMONT XE, XF WAGON
FORD FAIRMONT 1988-1994 - FAIRMONT EA, EB, ED WAGON
FORD FAIRMONT 1994-1996 - FAIRMONT EF WAGON
FORD FAIRMONT 1996-1998 - FAIRMONT EL WAGON
FORD FAIRMONT 1998-2002 - FAIRMONT AU WAGON
FORD FALCON 1966-1969 - FALCON XR, XT
FORD FALCON 1969-1972 - FALCON XW, XY
FORD FALCON 1972-1976 - FALCON XA, XB
FORD FALCON 1976-1979 - FALCON XC
FORD FALCON 1979-1982 - FALCON XD WAGON, UTE AND VAN
FORD FALCON 1979-1982 - FALCON XD SEDAN
FORD FALCON 1982-1993 - FALCON XE, XF WAGON, UTE AND VAN
FORD FALCON 1988-1994 - FALCON EA, EB, ED WAGON
FORD FALCON 1993-1996 - FALCON XG UTE AND VAN (SHOCK FRONT END)
FORD FALCON 1994-1996 - FALCON EF WAGON
FORD FALCON 1996-1999 - FALCON XH UTE AND VAN (STRUT FRONT END)
FORD FALCON 1996-1998 - FALCON EL WAGON
FORD FALCON 1998-2002 - FALCON AU WAGON, UTE AND CAB CHASSIS
FORD FALCON 2002-2008 - FALCON BA, BF WAGON, UTE AND CAB CHASSIS
FORD FALCON 2008-2017 - FALCON FG, FGX UTE AND CAB CHASSIS
FORD LANDAU 1973-1979 - LTD P5, P6
FORD LTD 1973-1979 - LTD P5, P6
FORD LTD 1979-1982 - LTD FC
FORD MUSTANG 1964-1973 - MUSTANG CLASSIC 1ST GEN
FPV FALCON 2003-2007 - PURSUIT / SUPER PURSUIT BA, BF
