| Kits Required: | 1 |
| Warranty: | Limited Lifetime Warranty |
| Kit Contents: | 2 Shell Bushings, 2 Tubes, Install Guide, Grease |
| Install Guide: | Download Here |
| Bush Type |
Bush Qty |
OD (A) |
ID (B) |
L (C) |
FL (D) |
FLOD (E) |
C/Tube QTY |
C/Tube Size |
Similar Bushing Size |
| 16 | 2 | 60.2 mm | 26.4 mm | 54.4 mm | 14 mm | 34.7 mm | 2 | 27x14.3x54 mm | click here |
| Bush Type | 16 |
| Bush Qty | 2 |
| OD (A) | 60.2 mm |
| ID (B) | 26.4 mm |
| L (C) | 54.4 mm |
| FL (D) | 14 mm |
| FLOD (E) | 34.7 mm |
| C/Tube QTY | 2 |
| C/Tube Size | 27x14.3x54 mm |
| Similar Bushing Size | click here |
Looking for that hard-to-find part? Start your search here Nolathane Bushing Type & Size Register
| Install Guide |
Fitment Time |
Degree of Difficulty |
Recommend Wheel Alignment |
| Click to Download | 2.5 hrs | Trade Specialist | Yes |
| Press Sleeve # (IN) |
Press Plate # (IN) |
Press Sleeve # (OUT) |
Press Plate # (OUT) |
Support Sleeve # |
Press Plate # |
Threaded Rod # |
Press In/Out Kit |
| 08 | EVEN A | 07 | ODD A | 10 | EVEN A | M14 | NTK001 |
Use the above press Sleeves, Plates and Rods from the Nolathane Press In/Out kit NTK001 to aid in the ease of removing old worn and broken suspension bushings and installing New Nolathane bushings.
| Install Guide |
Fitment Time |
Degree of Difficulty |
Recommend Wheel Alignment |
| Click to Download | 2.5 hrs | Trade Specialist | Yes |
| Press Sleeve # (IN) | 08 |
| Press Plate # (IN) | EVEN A |
| Press Sleeve # (OUT) | 07 |
| Press Plate # (OUT) | ODD A |
| Support Sleeve # | 10 |
| Press Plate # | EVEN A |
| Threaded Rod # | M14 |
| Press In/Out Kit | NTK001 |
Use the above press Sleeves, Plates and Rods from the Nolathane Press In/Out kit NTK001 to aid in the ease of removing old worn and broken suspension bushings and installing New Nolathane bushings.
